WORM GEAR MOTOR

MOTOR:
direct current with permanent magnets, totally enclosed. Class F winding. 24 Vdc. Absorbed power 60 W. IP65 protection according to CEI EN 60529.

GEAR UNIT:
with die-cast aluminium case (UNI 5076). Centre distance 20 mm. CARO bronze ring, 120÷160 HB hardness. Hardened steel screw with ground thread. Fluoridated polymer (FPM) grommets. Lubrication with synthetic oil (EP).

6 reduction gear ratios are available: 10/15/25/45/60/80. Maximum rated torque is 5.2 Nm. Manufacture B3/B14.
